R15500,00
F5 is designed as a small power 4-stroke outboard motor, suitable for personal leisure and entertainment, and used to boats, rubber boats within 5 meters. F5 and F4 come from the same development plateform, so they can share most parts. Their light weights, combined with built-in carrying handles and an oil-leak prevention system for on-side storage capability create true portability. Add to that their efficiency, performance and reliability and these pint-sized powerhouses are perfect for all sorts of light duty.
High Lights
1. Exhaust through the middle of propeller so as to get low noise and low vibration for extra comfort;
2. Using imported key parts, the engine has better performance and longer service life.
3. Besides the oil dip-stick, also equipped with oil watch window.
4. Convenient auxiliary prime pump in cowling for easy starting after long storage.
5. CDI Ignition for easy start in all conditions: idle speed will be down to 1200~1300rpm (the fuel consumption will be reduced) and more quiet at idle speed by such new system.
SPECIFICATIONS
| Model | F5 |
| Specs Option | F5BMS/F5BML |
| Transom Height | 15in. or 20in. |
| Weight | 24.5Kg/25.5kg |
| Full Throttle Operating Range | 4000～5000r/min |
| Maximum Output Power | 3.6kW（5HP）@5000r/min |
| Idling Speed Range | 1500～1600 r/min |
| Engine Type | OHV |
| Displacement | 112 cc |
| Bore*Stroke | 59.0×41.5 mm |
| Ignition System | TCI |
| Steering System | Tiller |
| Start System | Manual start |
| Gear Positions | F-N-R |
| Gear Ratio | 2.08 |
| Trim and Tilt System | Manual |
| Fuel Tank Capacity | Built-in 1.3L |
| Max. Fuel Consumption | 2.0L/h |
| Engine Oil Capacity | 0.5L |
| Gear Oil Capacity | 100cc |
| Propeller Potions | 3-7″in. |
